Brand Name : SPEEDATA
Model Number : SD55
Certification : CE/ISO9001/IP65/3C/CTA//FCC
Place of Origin : Beijing China
MOQ : 1 piece
Payment Terms : L/C, T/T, Western Union, MoneyGram
Delivery Time : 10000pcs/month
Packaging Details : Standard Independent Carton Box with Accessories
Name : Data Terminal Mobile Phone PDA
OS : Android 8.1
CPU : Octa-Core 2.0GHz
RAM : 4GB
ROM : 64GB
Expansion : Micro SD (TF) card slot up to 128GB
Camera : Rear camera 13MP AF; Front Camera 5MP FF (Autofocus )
Display : 5.5 Inch Full Screen 720*1440
Barcode Scanner : 1D/2D: Honeywell N6603 or Speedata SD5670
WLAN : 4G/WiFi/GPS
Battery : Li-ion 4500mAh
Certificate : CCC/CTA/CE/FCC/ISO9001/IP65




| SD55LG Basic Parameters | |
| OS | Android 8.1 |
| CPU | Octa-Core 2.0GHz |
| RAM | 4GB |
| ROM | 64GB |
| Expansion | Micro SD (TF) card slot up to 128GB |
| Keypad | 5 side buttons,2 volume buttons,2 function buttons(1 left and right),1 power button |
| Audio | 1609 Dual speakers,waterproof design,Dual silicon mic noise reduction |
| Notification | Sound/vibration/LED prompt |
| Dimentions | 150mm*72.5mm*15mm |
| Weight( with battery) | 200g |
| Camera | |
| Camera | Rear camera 13MP AF(16MP PDAF option);Front Camera 5MP FF |
| Focus mode | Autofocus ; Front focus |
| Flash | Support single color LED flash |
| Display | |
| Display | 5.5 Inch Full Screen |
| Resolution | 720*1440 |
| Touch Panel | 5-point capacitive touch screen |
| Power | |
| Battery | large-capacity unremovable Li-ion battery 4500mAh |
| Charging | PE fast charging, fully charged time< 4 hours Wireless charging QI standard, 5w or 10w |
| Interface | support USB-TypeC, support fast charge, support OTG |
| Communication | |
| GPS | BT4.0 BLE |
| WLAN | WiFi 802.11 a/b/g/n 2.4G 5G |
| WWAN | FDD-LTE B1/B3/B5/B7 or B1/B4/B8/B13 TDD-LTE B38/B39//B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8 CDMA1x/CDMA2000 BC0 |
| GPS | GPS,GLONASS,BeiDou,AGPS,option UBLOX8030 |
| Performance | |
| Operation Temperature | -20℃ ~60℃ |
| Storage Temperature | -30℃ ~+80℃ |
| Humidity | 5%~95%(No condensation) |
| Sealing | IP65 |
| Sealing | In the operating range, 6 sides can withstand the impact of 1.5 meters drop to the concrete floor |
| Tumble Test | 6 contact surfaces rolling for 1000 times/ 0.5M |
| ESD | ±15kV Air Discharge, ±8kV Contact Discharge |
| Certificate | CCC,CTA,CE,FCC |
| Extensibility | |
| NFC RFID Reader | NFC (PN548) Support NFC Reader/writer, ISO14443-A/B/F, ISO18092, FeliCa, MIFARE, ISO15693 |
| Barcode Scanner | 1D/2D: Honeywell N6603 or Speedata SD5670 |
| PSAM | support |
| Sensor | geomagnetism, acceleration, light perception distance,berometer(optional), gyroscope (optional) |
Yes, Of course. We can provide 1 sample Terminal PDA for your testing.
As a manufacturer of barcode scanner terminal PDA,the more you buy, the cheaper it'll be.
The sample price is a little bit higher than the common wholesale price excluding the freight fee.
1.We provide you Free SDK and Technical Support for your Barcode Scanner.
2.We also provide ODM/OEM Customization Services based to your demands.
3.We support 13 months Warranty for all the device and 6 months for the batteries. Exend warranty, it costs 10% at the first year, and 15% for the second year.
1.It's generally 30%-100% TT in advance for all orders. Meanwhile, Paypal or West Union is acceptable.
2. FOB Shenzhen as Trade Term.
1. Our products have been sold to worldwide,especially market in South/North America, Europe, Asia, Africa Mid-east, etc.
2.The market share is increasing quickly every year and we get more and more positive feedbacks from our customers.
|
|
Octa 2.0GHz Mobile Phone PDA 4GB RAM 64GB ROM Android 8.1 Images |
